SURFBOARDS
R
THE BREADBOARDING MEDIUM FOR
SURFACE MOUNT
TM
33000 SERIES APPLICATION SPECIFIC ADAPTERS
IDS33623
REV 1-2012
MODEL
33623
B
A
SOT-223
SC-73
FOR HIGHER CURRENT APPLICATIONS
ALWAYS CONSULT DEVICE DATA SHEET TO INSURE PROPER FIT
SAME DEVICE FOOTPRINT AS MODEL
33223 EXCEPT WITH 2 OUTPUT PINS PER
DEVICE LEAD FOR HIGHER CURRENT.
NOTE: CIRCUIT TRACE
FOILS AND OUTPUT
PINS MAY NOT BE
SUITABLE FOR
DEVICE OPERATION AT
I
D
H
HIGHEST RATED
CURRENT LEVELS.
EXTREME
TEMPERATURE RISE
MAY RESULT IN
F
FAILURE.
SINGLE-IN-LINE
( SIP ) PINS ON
G
E
DEVICE FOOTPRINT
.1 in.CENTERS.
2 PINS PER
C
DEVICE LEAD.
SEE PIN SPECS.
PIN SPECIFICATIONS / TOLERANCES
In Inches
A = .062 +- .006
FIG.
A
B
C
INCHES
.500
.600
.100
MM
12.70
15.24
2.54
NOTE:
BOARD HEIGHT +- .5mm .020in.
BOARD WIDTH +- . 5mm .020in .
SIP PIN SPACE +- .20mm .008in.
B = .130 +- .010
C =.100 +- .005
D = .020 +- .004
E = .031 +-.005
D
.275
6.98
PAD CENTERLINE
BOARD
SPECIFICATIONS
E
F
G
H
I
.090
.080
.055
.185
.365
2.28
2.03
1.39
4.69
9.27
DEVICE LEAD PITCH
PAD LENGTH
PAD WIDTH
GAP
MAX PIN WIDTH
RoHS
Compliant
EC 2002/95
BOARD MATERIAL : .8mm, +-.13mm .031in+-..005 in.
Thick G-10 FR-4 Glass Epoxy or equivalent.
CIRCUITS : 1 oz. Copper with RoHS compliant Lead
Free solder coating. Patten Position on board +-
.5mm .020in.
TOLERANCES: If not noted are +- 20%. Nominal values are given.
Controlling unit is Millimeters. Values rounded to nearest decimal. Slight
Variations due to manufacturing process can occur.
Copyright 1997-2012 by Capital Advanced Technologies, Inc. All rights reserved. Surfboards is a registered trademark of Capital Advanced Technologies, Inc. The Breadboarding medium for surface mount, and the
Leaf Circuit Logo are trademarks of Capital Advanced Technologies, Inc. All other trademarks are the property of their respective owners. Specifications, availability, and price is subject to change without notice. All
information given is believed to be accurate but is not guaranteed. The user of information given or products represented by such information is responsible for determining the suitability of said information or products for
a given purpose. No inducement is intended or permission granted for infringement of any patent or unauthorized use of any intellectual property of Capital Advanced Technologies or others.
CAPITAL ADVANCED TECHNOLOGIES, INC.
CAROL STREAM, ILLINOIS. USA.
PHONE 630-690-1696
WWW.CapitalAdvanced.Com
FAX 630-690-2498
